Four Post Hoists

  • 4 post, 5.5 ton Wheel Alignment Lift
  • Excellent value for money hoist.
  • Hydraulic cylinder located in the fixed platform and is thus perfectly protected.
  • High resistance galvanized and pre-stretched lifting cable.
  • Lock release lever for the emergency situation.
  • Adjustable parking ratchet rails ensure the platforms and cross members horizontal within 4 wheel alignment tolerances.
  • Self lubricated large diameter pulleys and maintenance-free bushes.
  • Includes 1x 3 ton scissor jack.
  • 2nd Rolling jack $1,495 + gst
  • Electric remote-controller. (OPTION)



Lifting Capacity (kg)                :Body : 5,500 / Jack : 3,000 kg
Max Lifting Height (mm)       :Body : 1,896 / Jack : 375 mm
Dimension (mm)                       :6,288(L) X 3,352(W)
Power Supply & Motor           :1ph : 2.2kw, 4P, 220V, 50/60Hz
                                                         :3ph : 2.2kw, 4P, 220/380V, 50/60 Hz

  • 4 post, 4 ton Flat Platform Lift
  • Hydraulic cylinder located in the fixed platform and is thus perfectly protected.
  • High resistance galvanized and pre-stretched lifting cable.
  • Lock release lever for the emergency situation.
  • Adjustable parking ratchet rails ensure the platforms and cross members horizontal within 4 wheel alignment tolerances.
  • Automatic spring loaded eccentric brake system in the event of cable breakage and ensures complete stability during parking.
  • Self lubricated large diameter pulleys and maintenance-free bushes.
  • Hydraulic two-level 2ton scissor jack. (OPTION)
  • Detachable align platforms. (OPTION)
  • Electric remote-controller. (OPTION)



Lifting Capacity (kg)                :Body : 4,000 / Jack : 2,000 kg
Max Lifting Height (mm)       :Body : 1,750 / Jack : 455 mm
Dimension (mm)                       :5,295(L) X 3,360(W) X 2,215(H)
Power Supply & Motor           :1ph : 2.5HP, 4P, 220V, 50/60Hz
                                                         :3ph : 2HP, 4P, 220/380V, 50/60 Hz

  • 4 post, 4.5 ton Flat Platform Lift
  • Hydraulic cylinder located in the fixed platform and is thus perfectly protected.
  • High resistance galvanized and pre-stretched lifting cable.
  • Lock release lever for the emergency situation.
  • Adjustable parking ratchet rails ensure the platforms and cross members horizontal within 4 wheel alignment tolerances.
  • Automatic spring loaded eccentric brake system in the event of cable breakage and ensures complete stability during parking.
  • Self lubricated large diameter pulleys and maintenance-free bushes.
  • Electric remote-controller. (OPTION)
  • Step-up plates for worker’s convenience. (OPTION)
  • Turn-table pocket. (OPTION)
  • Hydraulic two-level 2ton scissor jack. (OPTION: $1,745 + gst each)
  • Alignment kit (OPTION: $1,795 + gst)



Lifting Capacity                       :Body : 4,500kg / Jack : 2,500 kg
Max Lifting Height (mm)      :Body : 1,740kg / Jack : 455 mm
Dimension (mm)                     : 5,859(L) X 3,416(W) X2,212(H)
Power Supply & Motor          :1ph : 2.5HP, 4P, 220V, 50/60Hz
                                                       :3ph : 2HP, 4P, 220/380V, 50/60 Hz

  • 4 post, 4 ton Alignment Lift
  • Hydraulic cylinder located in the fixed platform and is thus perfectly protected.
  • High-resistance galvanized and pre-stretched lifting cable.
  • Adjustable parking ratchet rails ensure the platforms and cross members horizontal within 4 wheel alignment tolerances.
  • Automatic spring loaded eccentric brake system in the event of cable breakage and ensures complete stability during parking.
  • Self lubricated large diameter pulleys and maintenance-free bushes.
  • Auxiliary lift table built in the platforms for wheel free operation.
  • Auto-pneumatic rear slip plates locking device.
  • Front turn-table recesses and rear sliding plates for 4-wheel alignment operation.
  • Descend alarm signal. (CE)
  • Two step descending system gives full foot protection. (CE)
  • Hydraulic hand-pump for emergency ascend/descend. (CE)
  • De-synchronization detecting electronic photo-cell. (CE)
  • Lighting kits 4pcs. (OPTION)



Lifting Capacity                           :Body: 6,000kg / Jack: 3,000 kg
Max Lifting Height (mm)          :Body: 1,750 / Jack: 595 mm
Dimension (mm)                         :7,384(L) X 3,616(W) X 2,215(H)
Power Supply & Motor              :3ph: 3HP, 4P, 220/380V, 50/60Hz

  • 4 post, 6 ton Flat Platform Lift
  • Now also available as 8 ton or 10 ton
  • Hydraulic cylinder located in the fixed platform and is thus perfectly protected.
  • High resistance galvanized and pre-stretched lifting cable.
  • Lock release lever for the emergency situation.
  • Adjustable parking ratchet rails ensure the platforms and cross members horizontal within 4 wheel alignment tolerances.
  • Automatic spring loaded eccentric brake system in the event of cable breakage and ensures complete stability during parking.
  • Self lubricated large diameter pulleys and maintenance-free bushes.
  • Electric remote-controller. (OPTION)
  • Hydraulic two-level 2ton scissor jack. (OPTION: $1,745 + gst each)
  • Hydraulic two-level 3ton scissor jack. (OPTION: $2,195 + gst each)
  • Alignment kit (OPTION: $2,195 + gst)

Lifting Capacity                       :Body: 6,000kg / Jack: 3,000 kg
Max Lifting Height (mm)      :Body: 1,750 / Jack: 595 mm
Dimension (mm)                     :7,384(L) X 3,616(W) X 2,215(H)
Power Supply & Motor         :3ph: 3HP, 4P, 220/380V, 50/60Hz
